Flexible Silicone Rubber Industrial Heating Pads
Silicone Rubber Heating Pad
Silicone Drum Heater is beneficial to take out liquid and coagulum
from drums easily by heating, such as adhesive, oil, asphalt,
paint, paraffin wax, oil and various resin raw materials in the
drum. It can make viscosity of materials descending and uniform by
heating the drum, and reduce the power of pump. Therefore, the
heater does not be restricted by seasons, and can be used
throughout the year
Flexible Silicone Rubber Heater Specifications:
Temperature controller | Dial, Digital thermostat or thermistor, thermal protection or
thermocouples, Velcro, Spring buckle |
| 1.PP bag and carton boxes
2.inner anti-collision broken plastic
3.outer wooden case |
Power lead wire | Silicone rubber, SJ Power Cord, or Teflon insulated stranded wire |
Model | Heater for drum(200L) | Heater for pail can(200L) | Heater for ltto can(200L) |
Dimensions | 250*1740mm | 145*1700mm | 125*1740mm |
Electric Data | 220v 2000w | 220v 1500w | 220v 1000w |
Weight | appr 1.3kg | appr 1.2kg | appr 1.1kg |
Temperature Range | 30-150℃ | 30-150℃ | 30-150℃ |
Flexible Silicone Rubber Heater Advantages:
1. Design according to actual shape and dimension, and your
equipment.
2. Moisture-proof chemical defense silicon rubber material makes
the service life of heater much longer.
3. It can be simply pasted or attached to your component by
vulcanizing, adhesive or fastener, etc.
4. High thermal efficiency: The temperature of the electric heating
film itself is only tens of higher than that of the liquid when
heating, which is 2-3 times energy saving than ordinary electric
stoves.
5. Easy application: Its self-insulation and free-of-open-fire
property greatly help simplify the techniques of heat preservation
and thermal insulation.
6. Its wide range of temperature, 250°C ~300°C, can not be simply
achieved by other electrical appliances.
7. Long service time: Under normal use, the product almost can be
permanently and continuously used because nickel and chrome
materials are durable to any corrosion, and the silicon has a high
surface resistance up to 100kg/cm², which is uncomparable for any
other electric heaters.
8. Made in any size, the temperature of the product can be
precisely adjusted by temperature controller.
Flexible Silicone Rubber Heater Application
The silicone rubber heater can be used for mixing and heat
preservation (oil drum heater) in industrial equipment, pipes,
tanks, and can be used in blood analyzer, corset, test tube
heating, etc..
It can be directly wrapped around the surface of the object to be
heated when in use.
